2, applicable materials: plastic, jade, crystal, wood products, rubber, organic glass, paper and other non-metallic materials.

3, applicable areas:

Mainly used for small craft gifts engraving, cutting. Such as: engraved portraits, badge, badges, all kinds of craft gifts packaging carving processing, small craft gift engraving, at the same time, the function of seal engraving, crab. Applies to all kinds of handicraft carving

4, technical parameters:

The laser power standard 50W (optional 60W/

80W)

Laser type: sealed off CO2 laser tube

Power supply voltage AC110-220V + 10%/50-60Hz

The maximum width 500mmx300mm

Engraving speed 800mm/s

Cutting speed 80mm/s

Positioning accuracy: 0.1mm

Positioning mode: manual positioning + red light positioning

Minimum forming character: Chinese characters: 2 x 2mm letter: 1 x 1mm

Working temperature 5 -35 C C

Resolution 0.015mm

Control configuration four generation DSP control system /USB offline

/U disk / Caixian

Data transmission interface USB data cable /U disk /LAN

System environment XP/Win 7/8 WINDOWS

Cooling mode

Graphics format supports PLT, DXF, AI, CDR, BMP

Engraving thickness: 0 - 10mm

Cutting thickness: 0 - 18mm

Lifting platform: manual lifting (optional electric lift)

(lift height 0-300mm)

Water protection (YES)

The slope is carved with 360 degree slope and the slope is arbitrary.

950750x550 (mm)

Package size

Weight 70 kg

Optional accessories: cooling water tank, roller platform, laser equipment

Dust remover,

5, other introduction:

Appearance design compact, easy to operate; the use of DSP high-speed computing chip motion control card, can be directly output under CoreIDRAWCAD, offline work, and has the most advanced power continued carving, U disk transmission and other functions. Stable performance, can be arbitrary design, carving a variety of patterns and text. The latest CDR software direct output, easy to operate and easy to operate to adapt to the small batch production; support graphics format all the CORELDRAW, can be identified in the file format; engraving thickness of 0 - 10mm (cutting depth is only for reference, mainly depends on the quality of the material and customer requirements). Suitable for small gifts such as engraving, cutting, carving portraits, badges, badges, all kinds of craft gifts.
